The BW-40LDR is a heated, mixed, vacuum-controlled stainless steel reactor vessel optimized for decarboxylation of 40L of crude extract in 2-3 hours depending on input material. It has the ability to remove volatile compounds under vacuum, making the terpene stripping portion of distillation extremely efficient. The BW-40LDR & includes an anti-foam system that allows for ‘set and forget’ operation; using a sensor, blow off valve, and an overhead stirrer with VFD for stirring and foaming prevention. Loading and unloading material can be done through a heated hose without opening the reactor. The BW-40LDR & also comes equipped with a cold trap for condensing of large volumes of volatile compounds. A Clean In Place (CIP) nozzle is integrated into the reactor for easy cleaning. If you need to process larger volumes of material, Beaker & Wrench also offers the BW-200LDR as well as custom equipment.
BW-40LDR Features
BW-40LDR
cUL-508A
Male Nema 14-30
230VAC, 1ph, 32A
2-3 hours for 40L of material
316 Stainless Steel
Dry Ice/ Liquid Nitrogen or Optional -55℃ Chiller
10 Torr Ultimate Vacuum
49”[1.2m] x 20"[0.5m] x 78”[2.0m]
400lbs
